Construction Drawings and Specifications

Mountain Regional Water District requires all new as well as remodeled residential and commercial connections to the district's current water infrastructure to follow uniform drawings, specifications, and standards. All drawings must still be approved by the District engineering staff prior to any construction. These documents are provided below:



METER SERVICES FOR HOMES

New homes require a District approved water meter, meter pit and lateral piping system connecting the water main to the home. This condensed plan set show in detail those requirements for 3/4 inch through 2 inch residential type services.



Construction Specifications

 New water infrastructure construction as well as subdivision or related project development construction requires compliance to these standards and drawings. Click below to download a copy of the latest District's Construction Standards and Specifications Book.


Rolled Construction Plans.jpg

Construction Drawings

For the detailed PDF drawings referenced in the Construction Standards and Specifications book above, please click below to download the full set. If you need a JPEG version of these drawings, please contact our office.



Autocad version of Drawings

An AUTOCAD DWG version of the drawing file above is provided here, to assist in the inclusion of any drawings of a water project as provided by a consulting engineer.



PRessure Reducing & Metering Stations

If your subdivision or development requires a pressure reducing station PRV (above ground - or below ground), you can find those plans here. The above ground PRV station plan is also used for above ground metering on large projects.
